Powerful Capability for Limitless Adventure
ENGINE TYPE
997 CC V-Twin Cylinder
MAX POWER
83 HP
TRANSMISSION
CVT System
POWER STEERING
Tri-Mode Dynamic EPS
4,500 LBS
Front Winch
Vehicle Specs
Engine Type : 997 C.C V-TWIN CYLINDER, SOHC WITH LIQUID COOLING
Horsepower : 83 HP
Max Torque : 90 Nm
Transmission : CVT (ELECTRONIC DRIVE BELT PROTECTION)
Drive System : SELECTABLE 2WD / RWD / 4WD / 4WD LOCK / TURF MODE
Fuel Capacity : 42L
Fuel System : ELECTRONIC FUEL INJECTION (EFI)
Gear Selection : L / H / N / R / P
Steering : 3 MODE DYNAMIC EPS (OFF/MIN/MAX)
Front Suspension : DOUBLE A-ARM IRS WITH 11″ TRAVEL W/ ANTI-ROLL BAR
Rear Suspension : DOUBLE A-ARM IRS WITH 11″ TRAVEL
Shock Absorbers : ADJUSTABLE/PRELOAD RING
Brake System : 4-WHEEL HYDRAULIC DISC BRAKE
Wheel Size : 14″ ALUMINUM
Front Tires : 27 × 9 – 14 RADIAL
Rear Tires : 27 × 11 – 14 RADIAL
Payload Capacity : 1830 LB (830 KG)
Rear Cargo Box Capacity : 1000 LBS (454 KG)
Front Rack Max Load : N/A
Rear Rack Max Load : N/A
Alternator (Electrical Charging System) : 1 DC 12V 10A 120W
Overall Length : 122 IN
Overall Width : 64 IN
Overall Height : 78.7 IN
Overall Weight (Dry) : 1642 LB (745 KG)
Wheelbase : 83.9 IN
Ground Clearance : FRONT: 13.4″ REAR: 14.2″
Hitch : 2″ RECEIVER
Cargo Box Size (L x W x H) : 42.5″ x 63″ x 12.6″
Hand Guard : N/A
Standard Instrumentation : 5″ TFT LCD DISPLAY
Lighting : WHOLE LED HEADLIGHT & TAILLIGHT, TURN SIGNALS
Front Bumper : YES
Seating : 3 SEATER CABIN
Winch : STANDARD EQUIPMENT – 4,500 LB WINCH
Rear Bumper : YES
Warranty : 2 YEAR LIMITED
ULTIMATE WORKHORSE
POWER FOR EVERY OCCASION
The TGB Landmax 1000 is your ultimate companion, equipped to handle any challenge with ease. From heavy-duty lifting to off-road adventures, count on the Landmax to have your back – and then some. Featuring 89.9 Nm of torque and advanced liquid cooling technology, it ensures unparalleled performance in every situation.
UNMATCHED UTILITY
CARGO BOX & 4,500 LBS WINCH
The Landmax makes every job effortless. With a cargo box capable of carrying 1,000 lbs, you can transport hefty loads with ease. Plus, its factory-standard front winch can handle up to 4,500 lbs, making tough tasks a breeze. Need to tow? No problem – the Landmax boasts a towing capacity of 2,500 lbs.
INNOVATION MEETS CONVENIENCE
Ultimate feel & comfort
Revolutionize your driving experience with the Landmax 1000, where innovation meets convenience. Featuring Tri-Mode Dynamic Electric Power Steering and a Tilt Steering Wheel, enjoy effortless control and customizable comfort on any terrain. Stay connected and powered up with a USB port, DC 12V 20A outlet, and a Battery Trickle Charging Outlet, while six strategically placed cup holders ensure refreshments are always within reach. With ample cabin space, stretch out and relax as you tackle your adventures with ease.
POWER WHEN YOU NEED IT
997cc 83HP Engine Drivetrain
With a 997CC V-Twin engine, the Landmax 1000 is capable on holding its own no matter what offroad challenges you throw at it. The 4-stroke, liquid cooled enginge delivers huge performance, top acceleration and powerful low end torque. Paired with an electronic fuel injection system along side a TGB designed and built CVT transmission, you’re guaranteed smooth and instant power.
FULLY CAPABLE POWERTRAIN
4 Configuration CVT Transmission
The Landmax 1000 is the ultimate all terrain vehicle. Whether you require superior road handling or are tackling the toughest trails, with TGB’s patented rear differential locking system you have access to a 4 configuration powertrain to fit your needs making it the ultimate toy for any user.
ELEVATE YOUR RIDE
14″ GROUND CLEARANCE
With a generous 14″ ground clearance, conquer any terrain with confidence and ease. Paired with sleek 14″ aluminum alloy wheel rims, this UTV not only looks the part but performs like a champ. Equipped with 27 x 9-14 radial tires in the front and 27 x 11-14 radial tires in the rear, the Landmax ensures superior traction and stability, whether you’re navigating rocky trails or smooth highways.
DIGITAL SPEEDOMETER
INDUSTRY LEADING IN DESIGN AND FUNCTIONALITY
With the ability to customize the display to show which functions are most important to you, easily track your vehicle history and data, or seeing which 2/4WD and power steering configuration you’re in at a glance are just some of the features packed into this feature rich display
